Panasonic Lumix S1R User Manual

6. Focus/Zoom
106

Move and Change the Size of the AF Area
1
Press [ ] to display the AF mode selection screen.
2
Select [ ], [ ] or [ ] and then press 4.
3
Press 3421 to move the position of
the AF area.
0
You can also move the AF area by
touching.
≥When [ ] is selected
– Press 34 to switch to a horizontal
pattern AF area.
– Press 21 to switch to a vertical pattern AF area.
≥When [ ]/[ ] are selected
– Positions can be moved to the diagonal directions using the joystick.
4
Rotate or to change the size of the AF area.
0
You can also pinch out/pinch in the AF area to change the size.
0 The first press of [DISP.] returns the AF area position to the centre. The second
press returns the size of the AF area to the default.
5
Press .
0 The display method for the AF area using 225-area focusing can be changed:
[] ¨ [ ] ¨ [AF Area Display] (l 341)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
