Panasonic Lumix S1R User Manual

14. Menu Guide
341
[Monitor / Display] ¨ ¨
[Photo Grid Line]
[ ]/[ ]/[ ]/`[OFF]
Sets the grid line pattern to be displayed on the recording
screen.
When using [ ], you can press 3421 to set the
position.
Positions can be moved to the diagonal directions using the
joystick.
0 When using [ ], you can also drag [ ] on the grid lines
on the recording screen to move the position.
0 This menu item can be registered to the Fn button.
(l 278)
[Framing Outline]
[ON]/`[OFF]
Displays the outline for the live view.
[Center Marker]
[ON]/`[OFF]
The centre of the recording screen will be displayed as [i].
[AF Area Display]
`[ON]/[OFF]
Displays the AF areas of [ ], [ ], [ ], [ ], and
[ ] to [ ].
0 AF areas are not displayed in the following cases:
– When [AFC Start Point (225-Area)] is not used during
[]
– When AF area shapes are not registered in [ ] to
[]
0 When the following functions are being used, [AF Area
Display] is not available:
– Video recording
– [6K/4K PHOTO]
ヤヒ
ヤピ
ヤヒ
ヤピ

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
