Panasonic Lumix S1R User Manual

9. White Balance/Image Quality
207

Setting the Type of Defocus ([Miniature Effect])
1
Set [Filter Effect] to [Miniature Effect].
2
Press 3 to display the setting screen.
0
The setting screen can also be displayed by touching [ ] then [ ].
3
Press 34 or 21 to move the in-
focus portion.
0
You can also move the in-focus portion by
touching the screen.
0 You can also switch the defocus orientation
by touching [ ].
4
Rotate , or to change the
size of in-focus portion.
0
The portion can also be enlarged/reduced by pinching out/pinching in the
screen.
0 To reset the in-focus portion setting to the default, press [DISP.].
5
Press or to set.
0 No audio is recorded in videos.
0 When video recording, the length of a recorded video will be approx. 1/8 of the
actual recording time.
(If you record for 8 minutes, the resulting video recording will be approx.
1 minute long.)
The available recording time displayed for this effect will be approx. 8 times
longer than for normal video recording.
Depending on the recording frame rate of the video, the recording time of the
video and the available recording time may differ from the values above.
0 If you end video recording after a short time, the camera may go on recording
for a certain period.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
