Panasonic Lumix S1R User Manual

9. White Balance/Image Quality
208

Setting the Colour to Be Left ([One Point Color])
1
Set [Filter Effect] to [One Point Color].
2
Press 3 to display the setting screen.
0
The setting screen can also be displayed by touching [ ] then [ ].
3
Press 3421 to move the frame and
select the colour you want to leave.
0
Positions can be moved to the diagonal
directions using the joystick.
0 You can also select the colour you want to
leave by touching the screen.
0 To return the frame back to the centre,
press [DISP.].
4
Press or to set.

Setting the Light Source Position and Size ([Sunshine])
1
Set [Filter Effect] to [Sunshine].
2
Press 3 to display the setting screen.
0
The setting screen can also be displayed by touching [ ] then [ ].
3
Press 3421 to move the centre
position of the light source.
0
Positions can be moved to the diagonal
directions using the joystick.
0 The position of the light source can also be
moved by touching the screen.
4
Rotate , or to adjust the
size of the light source.
0
This can also be enlarged/reduced by pinching out/pinching in the screen.
0 To reset the light source setting to the default, press [DISP.].
5
Press or .

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
