Panasonic Lumix S1R User Manual

2. Getting Started
34
1
Connect the charger and the
AC adaptor with the USB
connection cable (C–C).
0 Hold the plugs and insert them straight.
(Inserting these at an angle may cause
deformation or malfunction)
2
Connect the AC mains lead to
the AC adaptor and then
insert into the electrical
outlet.
3
Insert the battery.
≥Insert the terminal end of the
battery and push.
≥The [CHARGE] lamp A blinks and
charging begins.
0 Do not use any other USB connection cables except the supplied USB
connection cable (C–C).
This may cause malfunction.
0 Do not use any other AC adaptors except the supplied one.
This may cause malfunction.
0 Do not use any other AC mains leads except the supplied one.
This may cause malfunction.





Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
