2. Getting Started
35
[CHARGE] Lamp
Charging
status
0% to 49% 50% to 79% 80% to 99% 100%
[CHARGE]
lamp
A Blinking B Lit C Off
0 After charging, disconnect the power source connection and remove the
battery.
0 If the [50%] lamp is blinking quickly, then charging is not occurring.
– The temperature of the battery or surroundings is either too high or too low.
Try charging at an ambient temperature between 10 °C and 30 °C (50 oF
and 86 oF).
– The terminals of the charger or the battery are dirty.
Remove the connection to the power source, and wipe with a dry cloth.
