Panasonic Lumix S1R User Manual

14. Menu Guide
346
[Monitor / Display] ¨ ¨
[Zebra Pattern]
[ZEBRA1]/[ZEBRA2]/`[OFF]
[SET] [Zebra 1]/[Zebra 2]
This indicates areas where overexposure may occur in a
zebra pattern.
[ZEBRA1] [ZEBRA2]
Select [SET] to set the brightness to be processed as a
zebra pattern.
0 You can select a brightness value between [50%] and
[105%].
In [Zebra 2], you can select [OFF].
If you select [100%] or [105%], only the areas that are
already overexposed are displayed in a zebra pattern.
The smaller the value is, the wider the brightness range to
be processed as a zebra pattern will be.
0 This menu item can be registered to the Fn button.
(l 278)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
