Panasonic Lumix S1R User Manual

16. Connecting to Other Devices
437
0 If [USB Mode] is set to [PC(Storage)] in the [Setup] ([IN/OUT]) menu, the
camera will be automatically connected to the recorder without the [USB
Mode] selection screen being displayed. (l 355)
0 Do not use any other USB connection cables except the supplied USB
connection cables (C–C and A–C).
0 Take care not to turn off the camera while storage is in progress.
0 Images such as 4K videos may not be supported depending on your recorder.
0 Turn off the camera and disconnect the USB connection cable before
removing the card from the camera. Otherwise, the recorded data may be
damaged.
0 For the storage and playback procedures, refer to the operating instructions
for the recorder.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
