Panasonic Lumix S1R User Manual

17. Materials
507
Interface
USB SuperSpeed USB3.1 GEN1 Type C
Supports USB Power Delivery (9.0 V/3.0 A)
¢ Data from the PC cannot be written to the camera
using the USB connection cable.
HDMI HDMI Type A
[REMOTE] ‰ 2.5 mm jack
[MIC] ‰ 3.5 mm jack
Headphones ‰ 3.5 mm jack
Flash Synchro Ye s
Splash Resistant
Yes
Dimensions / Mass
Dimensions Approx. 148.9 mm (W)k110.0 mm (H)k96.7 mm (D)
(5.86q (W)k4.33q (H)k3.81q (D))
(excluding the projecting parts)
Mass Approx. 1020 g/2.25 lb (with one XQD memory card and
the battery)
Approx. 898 g/1.98 lb (camera body)
Operating environment
Recommended
operating
temperature
s10 oC
¢
to 40 oC (14 oF to 104 oF)
¢ The performance of the battery (number of
recordable pictures/operating time) may decrease
temporarily when using in a temperature between
s10 oC and 0 oC (14 oF and 32 oF) (cold places such
as ski resorts or places at high altitude).
Permissible relative
humidity
10%RH to 80%RH

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
