Panasonic Lumix S1R User Manual

17. Materials
508
35 mm full-frame interchangeable lens:
S-R24105 “LUMIX S 24-105 mm F4 MACRO O.I.S.”
Mount Leica Camera AG L-Mount
Focal length f=24 mm to 105 mm
Lens construction 16 elements in 13 groups (2 aspherical ED lenses,
2 aspherical lenses, 1 UED lens, 2 ED lenses)
Aperture type 9 diaphragm blades/Circular aperture diaphragm
Maximum aperture F4.0
Minimum aperture value F22
Angle of view 84o (Wide) to 23o (Tele)
Recording range 0.30 m (0.98 feet) to ¶ (from the focus distance
reference line)
Maximum image
magnification
0.5k
Image stabiliser Yes
Filter diameter 77 mm
Maximum diameter ‰84 mm (3.3q)
Overall length Approx. 118 mm (4.6q) (from the tip of the lens to the
base side of the lens mount)
Mass Approx. 680 g (1.4991 lb)
Dust and splash resistant Yes
Recommended operating
temperature
j10 oC to 40 oC (14 oF to 104 oF)
Permissible relative
humidity
10%RH to 80%RH

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
