Panasonic Lumix S1R User Manual

3. Basic Operations
69

Playback Screen
¢1 Pressing 34 switches the display information.
– Detailed information display
– Histogram display
– Photo Style display
– White balance display
– Lens information display
¢2 This is a screen without blinking highlights display that is shown when [Blinking
Highlights] of the [Custom] ([Monitor / Display]) is set to [ON].
In other than this screen, overexposed parts of the screen will blink. (l 345)
0 Press [ ] to switch between display/hide of the level gauge.
This can also be set by using [Level Gauge]. (l 339)
Control panel operation
You can touch items on the control panel to directly change their settings. These
can also be changed with the following operations:
1 Press one of the cursor buttons to enable
selection of items.
0 Selected items are displayed in yellow.
2 Rotate or to select an item.
0 You can also select by pressing 3421.
3 Rotate to change the settings values.
0 The types of screen to display on the monitor can be restricted:
[] ¨ [ ] ¨ [Show/Hide Monitor Layout] (l 345)
0 The display can be changed so that live view and display information do not
overlap:
[] ¨ [ ] ¨ [LVF/Monitor Disp. Set] (l 343)
With information
Detailed
information
display
¢1
Without
information
Display without
blinking
highlights
¢2
999
999
AWB
Fn
OFF
0 0
0
ISO
AUTO
AFS FINE
3:2
100-0001 1/999
ISO 100 F 4.060
L
FINE
10:00 1.DEC.2019
±
0
100
100-0001
ISO
0
F4.0 60
10:00 1.DEC.2019
s
RGB
1/5
FINE
AFS
STD.
L
3:2
AWB

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
