● Signal Inputs and Outputs - Connection X120B resp. 120C
Additional Galvanic Separation from Power and
Control Circuit
Nominal Voltage of the In and Outputs 24 V DC +20% / -10%
Number of Outputs
Signal Outputs via OPTO Coupler
4
resistive load Imax. = 2A
inductive load max. 1Henry
I
out
. Inductance
Max. Switching
Frequency
1A 1H 1Hz
1A 0,1H 10Hz
0,33A 1H 10Hz
0,2A 0,5H 50Hz
short-circuit current limited by (5A)
over-heating protection, active
overvoltage clamping (50V); keyed
Number of Inputs
Signal Outputs via OPTO Coupler
4
L = 0...7 V DC or open
H = 15...30 V DC
I
i
n
at 24VDC: 8 mA
Shortest Time for a Signal to All Inputs to Accept
the Signal in an Application:
> 1 ms
Damping of the Transfer from
Low to High (0-->24V):
default input:
200µs
Damping of the Transfer from
High to Low (24-->0V)
default input:
1000µs
● Digital Control
Current Control
Loop-Cycle-Time 105 µs
Settings according to factory specifications or
motor data
Current Limits - Adjustment by: speed control -menu
Analog Input
0..10V = 0..100%; can be standardized,
10Bit
Speed Control
Loop-Cycle-Time 105 µs
Settings speed control menu
Differential Setpoint Input Analog
Resolution (including sign)
U
soll
= 10 V, can be normed; R
i
= 10k
14 bit
Digital Setpoint Input via interfaces
Position Control
Loop-Cycle-Time 105 µs
