2.14 Overview of the Terminal Cross Section
Cross Section 638A 638B
[mm2] [mm2]
X60
Line,
Brakeresistor,
DC-Link
Solid Core /
Multiple conductor line
0,2-2,5
0,2-10
0,2-6
Flexible with ferrule
without plastic sleeve
0,25-2,5 0,25-6
Flexible with ferrule
with plastic sleeve
0,25-2,5 0,25-4
Flexible with TWIN-
ferrule with plastic
sleeve
0,5-1 0,25-1,5
Approbation Data
UL/C-UL-US
CSA
[AWG]
30-12
28-12
[AWG]
24-8
---
Stud Torque [Nm/Lib.in] 0,5-0,6/5-7 Spring tension
X01
Control
Voltage
X11
STO, Active
X62
Brake,
Thermo
Solid Core and
Multiple conductor line
0,14-1,5 0,14-1,5
Flexible with ferrule
without plastic sleeve
0,25-1,5 0,25-1,5
Flexible with ferrule
with plastic sleeve
0,25-0,5 0,25-0,5
Flexible with TWIN-
ferrule with plastic
sleeve
0,5-1 0,5-1
Approbation Data
UL/C-UL-US
CSA
[AWG]
30-14
30-14
[AWG]
30-14
---
Stud Torque [Nm/Lib.in] 0,2-0,22/2-4 0,2-0,22/2-4
X61
Motor
Solid Core /
Multiple conductor line
0,2-2,5
0,2-2,5
0,2-10
0,2-6
Flexible with ferrule
without plastic sleeve
0,25-2,5
0,25-6
Flexible with ferrule
with plastic sleeve
0,25-2,5
0,25-4
Approbation Data
UL/C-UL-US
CSA
[AWG]
30-12
28-12
[AWG]
28-8
---
Stud Torque [Nm/Lib.in] 0,5-0,6/5-7 0,7-0,8/7
X120
Option 2C8,
PC8, CC8
Solid Core and
Multiple conductor line
0,08-1,5 0,08-1,5
Approbation Data
UL/C-UL-US
CSA
[AWG]
28-14
28-14
[AWG]
28-14
---
