Parker 638 series

2 Connection Assignments and Functions
Connection Assignments and FunctionsConnection Assignments and Functions
Connection Assignments and Functions
07-02-12-02-EN-V1215.doc / Type: 638
31
2.8 Multi-Function X40
Description of the X40:
Via a programmable I/O processor, the X40 connection can be configured differently.
EASYRIDER

Windows - Software
Standard functions:
- Incremental output
- Incremental input
- Stepper motor - pulse inputs
- SSI interface
The unobstructed configurability provides ideal conditions for synchronous applications.
General Data X40
Plug Type: SUB D 09 male plug
Maximum Input or Output Frequency: 312 kHz
Maximum Cable Length - connected to
galvanically insulated terminals (Encoder, controls)
Maximum Cable Length - connected to ground
related terminals (other drives, controls)
Maximum Number of Signal Inputs - to one as
incremental output configured device
25 m;
For extended distances please contact our engineer
2 m,
Pay attention to provide for good common grounding !
8
Output Signals: Driver Model MAX483 or compatible, RS422
Differential Logic Level:
L ≤ 0,5V H ≥ 2,5V
Nominal Range: 0,0 ... 5,0V 60mA max.
Input Signals: Receiver Model MAX481 or compatible, RS422
Differential Input Level: Diff min = 0,2V
Nominal Signal Difference: 1,0V
Current Consumption: 1...4 mA (depending on the frequency)
Notice:
Master / Slave Operation
1 Master, Maximum 8 Slaves
Condition: Devices must be located directly side by side!
