Parker 638 series User Manual

12 Technical Data
Technical DataTechnical Data
Technical Data
114
07-02-12-02-EN-V1215.doc / Type: 638
● Digital Communication
RS232 - Service Interface COM1
19200 baud, 8 data bits, 1 start bit,
1 stop bit, parity: even
Optional
RS232 / RS422 / RS 485
on SUB D – Socket
COM2
CAN1, Profibus DP, SUCOnet K
on SUB D – Socket
Interbus S on SUB D – Socket (OUT)
Interbus S (Remote IN)
CAN2
additional on SUB D – socket
● X30 Resolver Evaluation / Transmitter Principles
General:
The specified data refers to the combination of the standard resolver interface with
Function Module - X300_RD2; operated with the Resolver R 21-T05, R15-T05
Maximum cable length without usage of the
Resolver cable KIR-B / KIR-G-UL
100m, with motor series ACM, ACR,
ACG, ACS, NX, EX, SMH, SMB
Carrier Frequency f
t
= 4,75 kHz
Ripple of the Actual Speed Value Signal 2%
1)
Max. Position Resolution for One Revolution 65536 / 16 bit
Absolute Position Accuracy +/- 0,7 °
1)
Relative Position Accuracy +/- 0,08 °
1)
1)
Data was checked – actual data results: Quality improved
