07-02-12-02-EN-V1215.doc / Type: 638
91
● Safety Password
The safety password must be entered in the appropriate field, every time that the Safety Parameter
Configuration screen is selected.
The password is always comprised of 4 letters.
The difference between large and small case letters is recognized.
The drive side initial factory setting of the password is “SAFE“.
The responsibility to set the new safety password lies with the operator of the equipment.
The new safety password should only be shared with authorized personnel,
for example: anyone who works on the STO, and/or has responsibilities in the areas of
equipment operating guidelines or equipment safety and security.
Flow Chart Diagram: Function X10.22 Acknowledgement + Emergency Stop
Flow Chart Diagram: Function X10.22 Acknowledgement
To Next Page
