Figure 13-3: A1450DD Vessel Head Assembly, View 2
Apply thread sealant (Loctite or equivalent) to 905DD, 902DD, (2) SA1632FT06, (2) 904DD, (2) SA1632RD06
A 1450 DD_S 2 R 2
1454DD FUNNEL REF
902DD GROUND STUD
905DD STANDOFF
898DD
(2) SA1632FP06
(2) PA1632PP06
899DD
(2) 904DD
RHMS 8-32 X 3/8
HEAD HANDLE
STANDOFF
CAP LOCATOR
FHMS 8-32 X 3/8
