parr 6400 - Figure 13-8: 6400 Cutaway Left

Parts Lists & Drawings
13
90
Figure 13-8: 6400 Cutaway Left
A 1435 DD_S 10 R 15
244VB
BULK HEAD
A1251DD
O2 SOLENOID
ASSY
(4) SA1632RP06
1381E TERMINAL BLOCK
(2) SA1140RD06 4-40 X 3/8 RHMS
354E2 SNAP BUSHING
1446DD HOUSING
(3) TN1332HL KEPS NUT
1425DD SHORT SPACER
(2) TA1332PP061L 6-32 X 3/8 PH PHILLIPS
897E CAPACITOR
1604DD CLAMP, CAPACITOR
1605DD BRACKET, CAP. MTG
(2) TN1332HL 6-32 KEPS NUT
(TORQUE NUTS TO 5 IN/LB)
(2) 1424DD
(2) TA1332PP06IL
(2) SA1332FS06
8-32 X 3/8 RHMS
SPACER
6-32 X 3/8 PH PHMS
6-32 X 3/8 FHSS SS
