Page 8-8 Lasair II Particle Counter Operations Manual

Chapter 8: Statistics Mode

Alarms in Statistical Mode

When the statistics mode is enabled, global alarms are automatically disabled. They

can, however, be manually enabled while in statistics mode.

When the statistics mode is disabled, global alarms will not be automatically re-

enabled. If the global alarms function is desired, it must be manually enabled.

Communications in Statistics Mode

When the statistics mode is enabled, TCP/IP is disabled.
