Particle Measuring Systems LASAIR II 550L - Statistics Data Table Screen

Observing Statistical Results
Lasair II Particle Counter Operations Manual Page 8-19
Statistics Summary Screen Softkey Function
Stop statistical sampling and exit the statistical mode. A pop-up dialog box
will ask for confirmation of this action.
Open the Statistical Sample Table Screen.
Open the Analog Data Screen.
Print Statistical Data.
Statistics Data Table Screen
This screen displays location status.
To open the Statistics Table:
1 From the Main Display, press the Statistics icon softkey to open the
Statistics Summary screen.
2 Press the Statistics Data Table icon softkey to open the Statistics Data
Table screen.
Max: Maximum concentration of all sampled locations
S.D: Standard Deviation
S.E.: Standard Error.
Table 8-5: Statistics Summary Screen Data (Continued)
Data Definition
