Page 3-10 Lasair II Particle Counter Operations Manual
Chapter 3: Controls and Displays
• Top and Bottom Banners: See Figure 3-3 above. The information displayed in
the banners are identical to those in the Main Display Screen. See Figure 3-1,
“Main Display Screen,” on page 3-5.
Setting Up the Display Screens
The display screens show a great deal of data. Parameters for the data reported on
these screens are set on several setup menus.
The table below is a reference that lists display items and the setup menu to use for
alterations. Any item that has more information on another display is also listed.
Field Setup Quick Reference Guide
Field Screen
From Main Display Screen,
press...
Location Name Sampling Setup 1st (top) softkey
Sampling Time/Vol. Sampling Setup 1st softkey
Delay Times Sampling Setup-Advanced 1st softkey
Sampling Units Sampling Setup-Advanced 1st softkey
Raw vs. Normalized
Data
Sampling Setup-Advanced 1st softkey
Auto-Print Sampling Setup 1st softkey
Alarms Alarm Setup 1st softkey; then press 3rd
softkey (Alarm)
Date and Time Main Setup 2nd softkey
Password Main Setup 2nd softkey
Language Main Setup 2nd softkey
Analog Name & Units Analog Data Setup 2nd softkey, then press 2nd
softkey (Analog Data)
Communications Comm Setup 2nd softkey; then press 3nd
softkey (Comm)
4-20 mA Output 2nd softkey; then press 4th
softkey
Battery Status 3rd softkey
Pump Status 3rd softkey
Laser Status 3rd softkey
Data Storage Status 3rd softkey
Software Version Status 3rd softkey
USB Download Status 3rd softkey
Data Review Status 3rd softkey
