Printer Output
Lasair II Particle Counter Operations Manual Page 6-15
Table 6-1: Printout Legend
Line
No.
Text or Data Description
1a
Final Sample Normalized
A sample will either be final or partial
depending on the state of the sample cycle
when the printer is run.
1b
Partial Sample Normalized
2
LASAIR II
The name/ID of the particle counter that
produced the data.
3a
006 Valid
006 identifies the location name where the
sample was drawn. Va li d indicates that the
Lasair II particle counter did not detect any
condition that would invalidate the sample.
3b
006 Invalid
Invalid indicates that the particle counter has
detected a condition that invalidates the
sample. Also see lines 17 and 18.
4
2007/12/06 12:01:00
Start of the sample
5
2007/12/06 12:01:05#1
A date stamp (year/month/day) followed by a
time stamp (hour:minute:second) when the
sample ended, and the number of the sample.
6
|| μ || Δ || ∑ ||
Column headers:
|| Particle size in microns || number of
particles detected of that size || The sum of all
particles counted of that size and larger.||
7
||0.3||6459381|| 7470894||
The 0.3 micron channel:
|| Total counts of 0.3 microns || Total counts
≥ 0.3 microns
8
|| 0.5|| 713777|| 1011512||
The 0.5 micron channel:
|| Total counts of 0.5 microns || Total counts
≥ 0.5 microns
9
|| 0.7|| 133677|| 297735||
The 0.7 micron channel:
|| Total counts of 0.7 microns || Total counts
≥ 0.7 microns
10
|| 1.0 || 117950 ||164058||
The 1 micron channel:
|| Total counts of 1 microns || Total counts
≥ 1 micron
11
|| 5.0 || 30024 || 46108 ||
The 5 micron channel:
|| Total counts of 5 microns || Total counts
≥ 5 microns
