Hierarchy of Screens in Statistical Mode
Lasair II Particle Counter Operations Manual Page 8-9
Hierarchy of Screens in Statistical Mode
The Lasair II particle counter uses a hierarchy of setup screens and displays. When
familiar with the hierarchy, you can navigate the screens and displays with greater
ease. Take some time to access the different screens so that you can build a picture
of the layout.
Sampling
Setup
Main
Setup
Status
Analog
Print
Alarm Setup
Statistics Setup
Recipes Setup
Analog Data Setup
4–20 mA Output Setup (optional)
Data Table
Sample Setup Printout
Data Display Setup
Data Sorting
& Filtering
Print Selected
Records
OR
Exit Statistics Mode
Statistics Table
Analog Data Display
Print Statistics Report
Main
Display
USB Data
Download
Communications
Setup
Statistics
Summary
Network Setup Page
Serial Port Setup Page
Data Display Setup Page
Main Sampling Setup
Location Name Setup
Advanced Sampling Setup
