Page 9-4 Lasair II Particle Counter Operations Manual
Chapter 9: Recipes
Recipe Setup Screen - Setup Page
Use this screen to create, delete, and print recipes. See Figure 9-1, “Recipe Setup
Screen, Setup Page,” on page 9-5.
Control buttons are as follows:
This button loads the highlighted recipe into the current settings for the
Lasair II particle counter.
This button saves the current sampling parameters to a recipe. A prompt for
the recipe name is displayed when this button is activated. The default
name is whatever recipe is currently highlighted. If an existing recipe name
is used, the recipe is replaced with the new parameters. A statistics recipe may be
re-written with a sampling recipe, and vice-versa. A copy of this button is also on
the Sampling Setup Screen for convenience in creating new sampling recipes.
This button saves the current statistics parameters to a recipe. It operates
like the save sampling parameters. For convenience, a copy of this button
is also on the statistics setup page.
This button deletes the currently highlighted recipe. A recipe cannot be erased
if it is attached to one or more locations. The location attachments must be
deleted first.
This button erases all recipes. A warning/confirmation prompt is
displayed before the recipes are erased. If locations are attached to
recipes, then either the attachments must be deleted, or the locations must be deleted
before the recipes can be deleted.
This button prints the highlighted recipe.
