Device Standards
Approved Cables for Electromagnetic Compliance
WARNING
The use of cables, transducers, and accessories other than those specified may
result in increased emissions of the ultrasound system.
Cables connected to the ultrasound system may affect its emissions. Use only the
cable types and lengths listed in Table 6-4.
Table 6-4 Approved Cables for Electromagnetic Compliance
Cable Type Length
Philips Part
Number
ECG 3-lead
safety connector
patient trunk
cable, AAMI
Shielded 2.7 m (9 ft) M1500A
ECG 3-lead
safety connector
patient trunk
cable, IEC
Shielded 2.7 m (9 ft) M1510A
ECG Aux input Shielded < 3 m (< 9.8 ft) --
Composite
video
Shielded coaxial Any --
S-Video Shielded Any --
LAN Twisted Pair Any --
Trigger Shielded < 3 m (< 9.8 ft) --
Foot switch Shielded 1.5 m (4.9 ft) Included with foot
switch assembly
RS-232 interface Shielded 2 m (6.5 ft) --
USB Shielded <3 m (10 ft) --
