Transducer Care and Maintenance
HD11 XE Getting Started
4535 612 62651
8
166
duration of contact are appropriate for the intended clinical use of the device.
Ensure that the disinfectant solution does not enter the device or the connec-
tor or come into contact with the connector label.
6. Air dry or towel dry with a sterile cloth according to the instructions on the
disinfectant label.
7. Examine the device and cable for damage such as cracks, splitting, sharp edges,
or projections. If damage is evident, discontinue use of the device and contact
your Philips Ultrasound representative.
Figure 8-2 Disinfecting Cables and Connectors
Wipe strain reliefs, cable, and
connector with a compatible
disinfectant
For cable disinfection, orient the device and the
connector facing up (strain reliefs on the bottom)
Locking lever shaft
Connector
strain relief
Strain relief
Electrical contacts
