Using the System
HD11 XE Getting Started
4535 612 62651
4
106
Tr a n s f e r r i n g D a t a
The printer, computer, or workstation to which you intend to send data must be
set up for serial data transfer as follows:
• 9,600 Baud
• 8-bit data
• No parity
• 1 stop bit
➤ To transfer data
1. Make sure the RS-232 serial cable is connected to the system.
2. Open a study, or create a new study.
3. Press Report.
4. Press the record key that you assigned as Serial Output. A confirmation
message appears.
Moving and Transporting the System
The weight of the system depends on the peripherals installed. Although the sys-
tem is designed to be mobile, the typical weight (including the monitor, but with-
out peripherals) is approximately 100 kg (220 lb).
WARNING
This weight dictates discretion when moving the system. The ability to move the
machine, is, however, directly related to an individual’s size and strength. Seek
assistance to move the system when necessary.
The system dimensions, including the display monitor are as follows:
Height 151.1 cm to 174 cm (59.5 in to 68.5 in)
Width 55.88 cm (22 in)
Depth 111.76 cm (44 in) from front of keyboard to rear of base
Weight < 100 kg (220 lb) without peripherals
