Philips HD11 XE - Figure 10-8 S7-3 t Scan Plane Rotation Control

10
HD11 XE Getting Started
4535 612 62651
223
TEE Transducers
Figure 10-8 S7-3t Scan Plane Rotation Control
CAUTION
Do not use excessive force on the scan plane rotation control wheel at its outer
positions because this may damage the endoscope mechanism.
1, 2
1. Radwin, Martin et al. “Transesophageal Echocardiography: Intubation Techniques.” Philips Appli-
cation Note 5091-2804E, 1992.
2. Urbanowitz, John H. et al. “Transesophageal Echocardiography and Its Potential for Esoph-
ageal Damage.” Anesthesiology, Vol. 72, No. 1, 1990.
Short axis
Angle= 0
o
Long axis
Angle= 90
o
Short axis
Angle= 180
o
