Table 4-2 lists and describes each connector.
For a description of each symbol on the I/O Panel, see the “System Input/Output
Connections” on page 139.
Figure 4-3 shows the system cart with the cables protruding through the access
hole. Each system comes standard with:
• Two power cords
•Two Universal Serial Bus (USB) cables
•VCR cables (two audio, two video, and one RS-232)
Ta b l e 4 - 2 Pe r i p h e r a l C o n n e c t o r s
Connector Description
Serial interface Connects the ultrasound system to an offline review
station
Network Connects the ultrasound system to a DICOM
network
USB Connects a plain-paper printer to the ultrasound
system
Foot switch Connects a foot switch to the ultrasound system
S-Video output Connects a generic VCR or video input printer to the
ultrasound system
B&W composite
video output
Connects a device such as a multi-format camera to
the ultrasound system
Color
composite video
output
Connects a video monitor or video input printer to
the ultrasound system
Print trigger
output
Connects a trigger to start a print on a video input
printer
Analog
telephone line
input
Connects an analog telephone line to the ultrasound
system for remote service assistance
