Using the System
HD11 XE Getting Started
4535 612 62651
4
94
Connecting Peripherals
This section provides information about how to connect optional peripherals to
your system.
ARNINGS
• Using accessories, transducers, peripherals, or cables not supplied with the
ultrasound system or not recommended by Philips can result in increased
emissions or decreased immunity of the ultrasound system.
• If you use additional peripheral equipment powered from an electrical source
other than the ultrasound system, the combination of the peripheral equip-
ment and the ultrasound system is considered to be a medical system. It is
your responsibility to comply with IEC 60601-1-1 and to test the system to
those requirements. For more information, see “Safety” on page 23. If you
have questions, contact your Philips representative.
• If you have a modem, make sure it is not connected to a telephone line while
you are performing an ultrasound exam on a patient.
Figure 4-2 shows where each peripheral is connected to the system. If you are
connecting more than one of the optional peripherals to the system and plan to
store them together on the cart, you need to place either the VCR or the color
printer tray between each peripheral. For more information, see “Printers and
Printer Accessories” on page 265.
