Figure 6-1 ECG and Physio Panel Connections
NOTE
The minimum amplitude on the ECG input for proper ECG signal processing is
0.25 mV. Signals below this level may cause inaccurate results.
W
ARNINGS
• Do not use ECG patient cables with detachable lead wires that have exposed
male pins. There is danger of electrocution if these pins are plugged into AC
power.
• Do not apply voltages of more than ±15 V with respect to ground to external
panel connectors.
Table 6-11 lists and describes the ECG and physio input parameters and values.
ECG cable connector
External physio input connector
