4
HD11 XE Getting Started
4535 612 62651
107
Using the System
Taking Precaut io n s Wh e n Moving t he System
Be careful when you move the ultrasound system. Although it is designed to be
mobile, remember that it weighs approximately 100 kg (220 lb). Therefore, take
the precautions described in this section when moving the system.
• Turn off the system and unplug it from the power source. Coil the power cord
on the hook that is located on the back of the system.
• If you have a LAN cable connected to the system, unplug it from the system’s
network jack.
• Always use the front handle to push the system. Do not push the system from
the side or the back. Do not use the handle to lift the system.
• Be sure the system control panel and monitor arm are locked. Rotate the
control panel left and right; it will lock automatically. See “Locking and
Unlocking the Monitor Arm” on page 81.
• Disconnect and remove external devices and all loose equipment from the
top of the system.
•Before transporting the system in a vehicle, remove transducers from the
holders, receptacles, and front cable holder.
• Make sure the strap that holds the system peripherals on top of the system is
securely tightened.
• When moving the system, never strap or secure the system above the handle.
•Use caution when moving the system over uneven surfaces. Do not move the
system over uneven elevator entrances by lifting up on the machine.
WARNING
Use two people to transport the ultrasound system when you are moving it up
and down ramps longer than 6 m (20 ft) or steeper than 5 degrees. (Wheelchair
ramps are usually less than 5 degrees.) It is, however, possible to exceed this
amount of incline when the system is moved over a roadside curb or some other
small but steep incline. Use extreme care when moving the system. Avoid ramps
that are steeper than 5 degrees to eliminate the potential danger of the system
tipping over.
