Safety
HD11 XE Getting Started
4535 612 62651
2
46
Equipotential
grounding
post
Used post for establishing common ground between
instruments.
Electrostatic
discharge
Warns the user not to touch exposed pins. Touching
exposed pins can cause electrostatic discharge, which can
damage the product.
Mercury
content and
proper
disposal
This symbol indicates that the system display contains
mercury. Dispose of properly in accordance with local, state,
or federal laws.
This symbol also indicates separate collection for electrical
and electronic equipment in compliance with the Waste
Electrical and Electronic Equipment (WEEE) Directive.
Recycle Dispose of properly in accordance with local, state, or
federal laws.
Global
Medical
Device
Nomencla-
ture
Indicates the symbol for the Global Medical Device
Nomenclature Code.
The following symbols may appear on the optional foot switch:
Record
pedal
Press this pedal to record the display image.
Print pedal Press this pedal to print the display image.
Freeze pedal Press this pedal to freeze the display image.
Table 2-3 Symbols Used on the System (Continued)
Symbol Meaning Description
˜
