User’s Manual of IGS-10020HPT-U
303
which the Packet Body
Length field is invalid.
Tx Total dot1xAuthEapolFrames
Tx
The number of EAPOL
frames of any type that have
been transmitted by the
switch.
Tx Request ID dot1xAuthEapolReqIdFr
amesTx
The number of EAPOL
Request Identity frames that
have been transmitted by
the switch.
Tx Requests dot1xAuthEapolReqFra
mesTx
The number of valid EAPOL
Request frames (other than
Request Identity frames)
that have been transmitted
by the switch.
• Backend Server
Counters
These backend (RADIUS) frame counters are available for the following administrative
states:
■ Port-based 802.1X
■ Single 802.1X
■ Multi 802.1X
■ MAC-based Auth.
Direction Name IEEE Name Description
Rx Access
Challenges
dot1xAuthBackendAcce
ssChallenges
802.1X-based:
Counts the number of times
that the switch receives the
first request from the backend
server following the first
response from the supplicant.
Indicates that the backend
server has communication
with the switch.
MAC-based:
Counts all Access Challenges
received from the backend
server for this port (left-most
table) or client (right-most
