Planet IGS-10020HPT-U User Manual

User’s Manual of IGS-10020HPT-U
342
• Power Supply Budget
[W]
Set limit value of the total PoE port providing power to the PDs.
• Temperature
Threshold
This is PoE temperature threshold for user set up a temperature parameter for
alarm.
• PoE Usage Threshold
This is a parameter for user to define that if PoE power has been consumed to
the setting then a alarm log will be issued.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
The wire gauge for the terminal block should be in the range of 12 ~ 22 AWG@25 degrees C.
PD Classifications
A PD may be classified by the PSE based on the classification information provided by the PD. The intent of PD classification is
to provide information about the maximum power required by the PD during operation. However, to improve power management
at the PSE, the PD provides a signature about Class level.
The PD is classified based on power. The classification of the PD is the maximum power that the PD will draw across all input
voltages and operational modes.
A PD will return to Class 0 to 4 in accordance with the maximum power draw as specified by Table 4-6-1-1.
Class
Usage
Range of maximum power used by the PD
Class Description
0
Default
0.44 to 12.95 watts
Classification unimplement
1
Optional
0.44 to 3.84 watts
Very low power
2
Optional
3.84 to 6.49 watts
Low power
3
Optional
6.49 to 12.95 watts (or to 15.4 watts)
Mid power
4
Optional
12.95 to 60 watts (or to 72 watts)
High power
Table 4-6-1-1 Device Class.
