Planmeca Compact i5 User Manual

NOTE
The light must be moved from the handles only. Do NOT move the light from
the arm or from the light body.
NOTE
The light beam may speed up the hardening of some filling materials. Move
the light so that the light beam is not directed towards the filling material or
turn on the operating light's composite mode.
NOTE
To be able to use the operating light hands-free with the gesture sensor, the
sensor must be enabled.
NOTE
The sensor detects your hand movement at an approximate distance of 3 -
18 cm (1.2 - 7.1 in.) from the infrared sensor.
The distance can be adjusted, see section "Gesture sensor" on page 196.
22.6.1 Indicator lights
The indicator lights on the operating light’s handle buttons indicate the
current state of the operating light.
22 Operating dental unit
118 Planmeca Compact i User's manual

Planmeca Compact i5 Specifications

General

Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental Unit
Power Supply	230 V, 50/60 Hz
Control System	Touch screen
Integrated systems	integrated suction system
Exposure Time Range	0.01 – 3.2 s
