Foot control power supply (optional)
Type: MENB1010A0903F01
Wireless foot control (optional)
Battery size: AA, HR6
Battery type: NiMH 1.2V, min 2000mAh, low self-discharge,
UL-listed (USA, Canada only)
Planmeca ProSensor power supply (optional)
Phihong Single Port Injector
Type: PSA16U-480 (POE)
Input voltage: 100-240 VAC (50-60 Hz)
Output voltage: 48VDC
Max. output current: 0.35 A
Insulation voltage
Primary-secondary 3000VDC
Suction system cleaning, Planmeca approved suction
disinfectant
Procedure Dosage Affect time
Suction system
cleaning
Suction disinfectant
concentration is 3.6%
Min. 2 minutes; can be
adjusted
Planmeca approved disinfectants for the suction system are Dürr Orotol
Plus and ORBI-Sept Evacuation System Disinfection Concentrate. For
more information on these disinfectants, please refer to the manufacturer’s
documentation.
35.2 Instrument classifications
The electrical classification of the instrument is marked on the instrument
hose either as B or BF. If there is no marking, no electricity flows through the
instrument.
Type B
Type BF
The following lists the instruments that are available for the Planmeca dental
unit and their electrical classification type.
Instrument classifications
Instrument Type
DCI autoclavable 3-way syringe B
Luzzani Ergo 3-way syringe B
35 Technical information
304 Planmeca Compact i User's manual
