13 Control panel
13.1 Control panel on instrument console
1. Sign out button 12. Bluetooth connection enabled (optional,
display only)
2. Patient recognition (display only) 13. Unit buttons
3. Time (display only) 14. Customisable swipe menu. Swipe to the side
to view more functions
4. Motorised headrest mode (optional, display
only)
15. Timer button
5. Date (if configured, display only) 16. Wireless foot control button (optional)
6. Maintenance button 17. Apex locator button (optional)
7. Assistant call / Door open 18. Touchpad button (optional)
8. Chair buttons 19. X-ray film viewer button
9. Wireless foot control battery (optional, display
only)
20. Solanna Vision button (optional)
10. User name (display only) 21. Program button
11. Romexis connection (optional, display only)
13 Control panel
User's manual Planmeca Compact i 73
