information, see sections "Instrument spray" on page 181, "Automatic chip
blow" on page 182 and "Instrument light" on page 183.
CAUTION
Before modifying the torque and RPM functions, please refer to the file
manufacturer’s instructions concerning torque and RPM value
recommendations for the files.
Steps
1. Activate the micromotor.
2. Press Torque.
The micromotor's drive mode is automatically set to Auto stop. This
means, that when the torque limit is reached, the micromotor stops. No
other drive modes are available for the Bien-Air MCX micromotor.
3. Press Program.
4. Press RPM limit to adjust the micromotor speed rate.
A pop-up window opens.
5. Adjust the micromotor speed rate (RPM).
Alteration of RPM speed rate in different ranges
Range In steps of:
100 - 200 10 (e.g. 110, 120 etc...)
200 - 500 20 (e.g. 220, 240, 260 etc...)
500 - 1 000 50 (e.g. 550, 600, 650 etc...)
1 000 - 2 000 100 (e.g. 1 100, 1 200 etc...)
2 000 - 5 000 200 (e.g. 2 200, 2 400 etc....)
5 000 - 10 000 500 (e.g. 5 500, 6 000, 6 500 etc...)
10 000 - 20 000 1 000 (e.g. 11 000, 12 000 etc....)
20 000 - 38 000 2 000 (e.g. 22 000, 24 000 etc....)
6. Press OK.
The pop-up window closes and the new value is displayed on the control
panel.
25 Programming
184 Planmeca Compact i User's manual
