F1, F2 = Schurter 0001.1014 10A/250V/FAST ACTING/HIGH BR CAP.
(100V, 115V)
F1, F2 = Bussmann S501-10-R 10A 250V FAST ACTING/HIGH BR CAP.
(100V, 115V)
F1, F2 = Schurter 0001.1012 6.3A/250V/FAST ACTING/HIGH BR CAP.
(220V – 240V)
F1, F2 = Bussmann S501-6.3-R 6.3A 250V FAST ACTING/HIGH BR CAP.
(220V- 240V)
F3, F4 = 4A/250V/Fast act./High br. cap, Schurter 0001.1010 OR
Bussmann S501-4-R
F5 = 8A/250V/Fast act./High br. cap, Schurter 0001.1013 OR Bussmann
S501-8-R
F6 - F8 = 6.3A/250V/Fast act./High br. cap, Schurter 0001.1012 OR
Bussmann S501-6.3-R
Power consumption
Idle unit: ≈ 60 VA (unit not in use, OP-light turned on)
Typical average: ≈ 350 VA (during patient treatment)
Maximum: 1450 VA (at maximum rated mains voltage, both
chair motors running)
Electrical classification
Class I
Operation of chair lift and backrest motors
Intermittent operation, ED 6%, 25 sec "ON", 400 sec. "OFF"
Water supply
Pressure range: min. 300kPa (44 psi), max. 900 kPa (130 psi)
In dental units with Planmeca WEK water
disinfection system, the pressure range must be
300 - 600 kPa (44 – 87 psi).
In dental units with Planmeca ActiveAqua water
treatment system, the pressure range must be
(100)200 - 900 kPa ((15)30 - 130 psi).
Flow rate: ≥ 4 l / min (maximum consumption at any
instance)
Quality: hardness; ≤ 8°dH
In dental units with Planmeca ActiveAqua water
treatment system, the water hardness can be 0 -
40°dH.
pH: 6.5 – 8.5
Connection: 1/4”
35 Technical information
302 Planmeca Compact i User's manual
