ELECTRICAL
10.3
GEAR POSITION INDICATOR
SWITCH
TEST
Switch Continuity Table
High Range
Neutral
Reverse
F
F
F
F
DCBA
F
F
High/Neutral/Reverse Switch
H/N/RSwitch
GRN/
LIMITER SPECIFICATIONS
NOTE: The part number is printed on some late
model LR modules. Whenever pos sible, use p art
number to identify the module. Modules may have
same “LR” I.D. number, with different part numbers,
terminals, and internal function.
Speed Limiter
Module LR
ID Number
Part number is printed
on module
LIMITER SPECIFICATIONS
(Refer to parts manual or microfiche for part num -
ber and application.)
TYPE FUNCTION / LIMIT RPM
LR44 Reverse Limit - 3500
