MAINTENANCE
2.17
damaged.
NOTE: When replacing the cover, check for correct
placement of cover O-ring.
FUEL SYSTEM
W ARNING
Gasoline is extremely flammable and explosive
under certain conditions.
G Always stop the engine and refuel
outdoors or in a well ventilated area.
G Do not smoke or allow open flames
or sparks in or near the area where
refueling is performed or where
gasoline is stored.
G Donot overfillthetank. Donot fillthe
tank neck.
G If you get gasoline in your eyes or if
you swallow gasoline, seek medical
attention immediately.
G If you spill gasoline on your skin or
clothing, immediately wash it off with
soapand water and changeclothing.
G Never start the engine or let it run in
an enclosed area. Engine exhaust
fumes are poisonous and can result
loss of consciousness or death in a
short time.
G Never drain the float bowl when the
engine is hot. Severe burns may
result.
FUEL LINES
Fuel Lines
Fuel Pump
Ill.1
Pulse Line
1. Check fuel lines for signs of wear, deterioration,
damage or leakage. Replace if necessary.
2. Besurefuellinesareroutedproperlyandsecured
with cable ties. CAUTION: Make sure lines are
not kinked or pinched.
3. Replace all fuel lines every two years.
VENT LINES
1. Check fuel tank, oil tank, carburetor, battery and
transmission vent lines for signs of wear,
deterioration,damageorleakage. Replaceevery
two years.
2. Be sure vent lines are routed properly and
secured with cable ties. CAUTION: Make sure
lines are not kinked or pinched.
FUEL FILTER
The fuel filter should be replaced in accordance with
the Periodic Maintenance Chart. The fuel filter is
located between the fuel pump and carburetor.
1. Shut off fuel supply at fuel valve.
2. Remove line clamps at both ends of the filter.
3. Remove fuel lines from filter.
4. Install new filter and clamps onto fuel lines with
arrow pointed in direction of fuel flow.
