BRAKES
9.24
REAR BRAKE CALIPER EXPLODED VIEW
TROUBLESHOOTING
Brakes Squeal
S Dirty/contaminated friction pads
S Improper alignment
S Worn disc
S Worn disc splines
Poor Brake Performance
S Air in system
S Water in system (brake fluid contaminated)
S Caliper/disc misaligned
S Caliper dirty or damaged
S Brake line damaged or lining ruptured
S Worn disc and/or friction pads
S Incorrectly adjusted lever
S Incorrectly adjusted stationary pad
S Wornordamagedmastercylinder orcomponents
S Improper clearance between lever and switch
Lever Vibration
S Disc damaged
S Discworn (runout or thickness varianceexceeds
service limit)
Caliper Overheats (Brakes Drag)
S Compensating port plugged
S Pad clearance set incorrectly
S Auxiliary brake pedal incorrectly adjusted
S Brake lever or pedal binding or unable to return
fully
S Parking brake left on
S Residue build up under caliper seals
S Operator riding brakes
Brakes Lock
S Alignment of caliper to disc.
