Polaris 2009 Trail Boss 330 Service Manual

NO REVERSE SPEED LIMIT
(LR44 Limit Module)
N
Y
REVERSE LAMP
ON?
APPLY PARKING BRAKE. START ENGINE.
SHIFT TO REVERSE GEAR
TEST GEAR POSITION INDICA-
TOR SWITCH AND INDICATOR
LAMP
Y
3V-9V AC AT
IDLE?
N
TEST WIRING
N
TEST VOLTAGE REGULATOR AND
CHARGING SYSTEM
MEASURE DC VOLTS O N
GRY/OR WIRE. TO GROUND
AT LR MODULE
MEASURE AC VOLTS ON
Y/R WIRE. AT LR MODULE
TO GROUND
Y
DISCONNECT BLACK
WIRE FROM LR MOD-
ULE AND CONNECT TO
GROUND.
ENGINE STOP?
N
TEST WIRING / TEST CDI (BLACK
WIRE)
Y
REPLACE LIMITER MODULE
12 VOLTS
DC?
ELECTRICAL
10.5
REVERSE SPEED LIMIT SYSTEM
