ENGINE
3.3
ES32PFE10 ENGINE SERVICE DAT
A
Cylinder / Piston / Connecting Rod ES32PFE10
Cylinder
Surface warpage limit (mating with cylinder
head)
.0020″ (0.050 mm)
Cylinder bore Std 3.0906-3.0913″ (78.50-78.520 mm)
Taper limit .0020″ (0.050 mm)
Out of round limit .0020″ (0.050 mm)
Piston clearance
Std .0015-.0032″ (0.038-0.082 mm)
Limit .004″ (0.11 mm)
Boring limit .0020″ (0.5 mm)
Piston Outer diameter
Std 3.0881-3.0891″ (78.438-78.462 mm)
.0098″ (.25 mm)
OS
3.0980-3.0989″ (78.688-78.712 mm)
.0197″ (.50 mm)
OS
3.1078-3.1087″ (78.938-78.962 mm)
Standard inner diameter of piston pin bore .7095-.7097″ (18.007-18.013 mm)
Piston Pin
Outer diameter .7092--.7095″ (18.001-18.007 mm)
Standard clearance-piston pin to pin bore 0.0-.0005″ (0.0-0.012 mm)
Degree of fit Piston pin must be a push (by hand) fit at 68°
F(20° C)
Piston Ring Piston ring installed gap Top ring
Std .0079-.0118″ (0.20-0.30 mm)
Limit .039″ (1.0 mm)
Second
Std .0138-.0197″ (0.35-0.50 mm)
ring
Limit .039″ (1.0 mm)
Oil ring
Std .0079-.0236″ (0.20-0.60 mm)
Limit .059″ (1.5 mm)
Piston Ring Standard clearance -
Top ring
Std .0014-.0030″ (0.035-0.075 mm)
piston ring to ring groove
Limit .0059″ (0.15 mm)
Second
Std .0010-.0026″ (0.025-0.065 mm)
ring
Limit .0059″ (0.15 mm)
Connecting Rod
Connecting rod small end ID .7095-.7101″ (18.007-18.023 mm)
Connecting rod small end radial
Std 0.0-.0009″ (0.0-0.022 mm)
clearance
Limit .0012″ (0.03 mm)
Connecting rod big end side clear-
Std .0028-.0118″ (0.07-0.30 mm)
ance
Limit .0138″ (0.35 mm)
Connecting rod big end bearing
Std 0.0007-0.0021″ (0.019-0.053 mm)
clearance
Limit 0.0026″ (0.065 mm)
Crankshaft
Crankshaft runout limit (PTO end) 0.0024″ (0.060 mm)
Crankshaft end play 0.002-0.008″ (0.05-0.20 mm)
KEY- Std: Standard;OS: Oversize;ID: InnerDiameter;
OD: OuterDiameter;Mag: Magneto Side; PTO: Power
Take Off Side
