GENERAL INFORMATION
1.7
MODEL: 2009 TRAILBLAZER 330..........
MODEL NUMBER: A09BA32AA.
ENGINE MODEL: ES32PFE..
Engine
Platform Fuji 4 stroke, Single Cylinder
Engine Model Number ES32PFE
Engine Displacement 329cc
Number of Cylinders 1
Bore & Stroke (mm) 78.5 x 68 mm
Compression Ratio 9.2:1
Compression Pressure 70--90 psi
Engine Idle Speed 1300 ± 100 Rpm
Cooling System/Capacity Oil/ Air w/ fan assist
1.9qts./1.8 ltr
Overheat Warning HOT Light on Panel
Lubrication Wet Sump
Oil Requirements Polaris 2W--50
Exhaust System USFS Approved
Carburetion
Carburetor model Mikuni BST 34mm
Main Jet 122.5
Pilot Jet 42.5
Jet Needle 4HB48--3
Needle Jet P--4 (829)
Pilot Screw 2 Turns Out
(Initial starting point, may vary
for each ATV)
Pilot Air Jet 160
Float Height 13 ± 1 mm (0.51 ± 0.40“)
Fuel Delivery Fuel Pump
Fuel Capacity / Requirement 3.25 gal. (12.3 L)
87 Octane (minimum)
89 Oxygenated
Electrical
Alternator Output 200 w @ 5000 RPM
Voltage Regulator 3--Phase
Lights : Head 55 watts
Brake 26.9 watts
Tail 8.26 watts
Ignition System DC/CDI Ignition
Ignition Timing 30°±2° BTDC @ 5000 RPM
Spark plug / Gap NGK BKR6E/ .036 in./0.9mm
Battery / Model / Amp Hr Maintenance--Free -- 14 Amp Hr
Circuit Breakers Harness 20 amp
Starting Electric / Recoil Backup
Indicator Panel Standard
Drivetrain
Transmission Type Inline H/N/R
Transmission Capacity 11.3 oz. (335 ml)
Gear Ratio : High
Rev.
Final
2.68/1
3.05/1
11/40 78P
Chain Type 520 O--Ring
Clutch T ype PVT Non EBS
Belt 3211077
Steering / Suspension
Front Suspension / Shock A--arm / MacPherson Strut
Front Travel 8.2 in. / 20.83 cm
Rear Suspension
Style / Shock
Progressive Rate Swingarm /
Twin Tube Gas Charged
Rear Travel 10.5 in. / 26.67 cm
Ground Clearance 5.5 in. / 13.97 cm
Shock Preload Adjustment
Front / Rear
Front -- n/a
Rear -- Cam
Turning Radius 83in./211cm
Toe Out 1/8 -- 1/4 in / 3 -- 6.35 mm
Wheels / Brakes
Wheel Size -- Front / Pattern 23 x 7 -- 10 / 4--156
Wheel Size -- Rear / Pattern 22 x 11 -- 10 / 4--102
Air Press. F/R Tires 4 psi Front / 3 psi Rear
Brake -- Front Dual Hydraulic Disc
Brake -- Rear Single Hydraulic Disc
Brake Fluid Polaris DOT 4 Brak e Fluid
JETTING CHART
Altitude
Meters
(Feet)
AMBIENT TEMPERATURE
0--1800
(0--6000)
above 1800
(above 6000)
Below 40°F
Below 5°C
+40°Fto+80°F
+5°Cto+28°C
127.5 122.5
120
115
CLUTCH CHART
Altitude
Meters
(Feet)
0--1800
(0--6000)
1800--3700
(6000--12000)
Shift
Drive
Spring
Driven
Helix
Weight
10 RH
20--40
45°
Blu/Grn
Blu/Grn
Driven
Spring
Black
Black
45°
(5131446)
(5131446)
(7041782)
(7041782)(7041157)
(7041157)
(5630709)
(5631356)
2--2
2--2
