Polyend Tracker Mini - System; Device Registration

209
Polyend Tracker Mini Manual
208
Polyend Tracker Mini Manual
NOTESNOTES
Tracker Mini’s limiter has the basic features of threshold which is where
limiting will kick in and also an attack / release envelope which shapes the
behaviour of the limiter function.
WT Smoother
The WT Smoother is a utility for converting normal audio samples into a
format more compatible with the wavetable play mode synth. Essentially
this optimises the interpolation between waves in a sample giving a
smoother transition across the sample. More details of the Wavetable synth
is provided in the instrument section.
While compression is normally seen as a master effect on many devices
and in DAW’s, Tracker Mini does not have a compressor in the master
chain and relies on the master limiter. A compressor does however exist in
the audio effects which can be rendered into the sample.
Limiter
A limiter is a similar utility to a compressor. In fact when high ratios are used
in a compressor, say 20:1, it is considered to be limiting. A limiter essentially
protects audio integrity and avoids excessive peaks by attenuating any
peaks above a dened threshold.
How does a limiter work?
Audio
8
Audio
8
BackThreshold
-12 dB
Attack
10.00 ms
Release
50 ms
Ratio
4.00
ApplyPreview
Sample Editor Compressor
8.beats
BackThreshold
-6 dB
Release
300 ms
Attack
3.00 ms
ApplyPreview
Sample Editor Limiter
8.beats
Threshold
Point in the audio level at
which the compressor is
activated
Threshold
Point in the audio level at
which limiting is applied
Ratio
Controls the amount of gain
reduction above the threshold
Release
Release time when
compression drops out
Release
Release time when limiter
drops out
Attack
Attack time when
compression kicks in.
Attack
Attack time when the limiter
kicks in.
Threshold
Audio over Time
Dynamic Range
Gain Reduction
Peak Limiting
Signal is attenuated when
crossing the threshold.
Tracker Mini threshold
range is 0% - 100%
