Powerscreen XA750S - Page 211

41-7
Powerscreen® XA750S
 49
 47
EN
P5 Magnetic Separator
[If 󰘰tted]
Locations · · · · · · · · · · · · · · · · · · · · 4
Lubricant · · · · · · · · · · · · · · · · · · · · D
Re-grease · · · · · · · · · · · · Every 2 weeks
n WARNING
The belt magnet assembly is very
powerful and permanently charged. The
strong magnetic 󰘰eld produced could
a󰘯ect heart pacemakers, watches, credit
cards, mobile phones etc. The operator
has the sole responsibility to keep anyone
at risk clear of the plant.
Persons with medical implants which may
be a󰘯ected by the magnetic 󰘰eld should
keep a minimum of 3m (10ft) away
12. Type ‘C’ track gearboxes are 󰘰tted to the plant,
refer also to servicing tracks.
P6 Track gearbox
Type C gearbox
Quantity · · · · · · · · · · 10 litres (2.6 US gal)
Normal ambient temperature:
From -20 to +30°C (-4 to 86°F) Lubricant · · · K
Higher ambient temperature:
From -10 to +45°C (+14 to +113°F) Lubricant · X
11. If 󰘰tted, refer also to servicing magnetic
separator.
