Servicing Magnetic Separator [if tted]
The self cleaning suspended magnet utilises a two
pulley design. The tail pulley has adjustment
available to take up belt stretch and for tracking
purposes.
n WARNING
The belt magnet assembly is very
powerful and permanently charged. The
strong magnetic eld produced could
aect heart pacemakers, watches, credit
cards, mobile phones etc. The operator
has the sole responsibility to keep anyone
at risk clear of the machine.
Persons with medical implants which may
be aected by the magnetic eld should
keep a minimum of 3m (10ft) away
1. Be sure the magnet frame is visibly square and
has not been damaged or twisted.
2. Check belt alignment.
3. Momentarily energise the belt drive and check
that the belt is tracking properly and is not
wandering laterally. Never start the belt and
allow it to run continuously until the belt is
properly “trained”. If the belt wanders, note the
direction and adjust as follows:
ENTANGLEMENT
HAZARD
n DANGER
Refer to Safety Notices Section for relevant
warning and procedure
Magnetic Separator - General [if tted]
Inspection
