10-11
Powerscreen® XA750S
1
1
2
2
3
EN
Safety Grid
NOTICE
Ensure that suitable lifting equipment
is used when putting the safety gate
into the transport position. Under NO
circumstances should the safety gate be
lifted manually.
1. Remove the two securing pins to allow the
safety grid to to rotate back into the transport
position.
2. Connect suitable lifting shackles and lifting
equipment to the lifting points on the safety
gate.
3. Raise the gate using the lifting equipment
and rotate the gate back 180° until the gate is
supported by it’s on weight.
4. Ensure the safety gate is completely lowered
before attemping to remove the chains and
shackles..
